Hustler Super 104
Ask to Rent this Product
If you are intersted in renting this product, please fill out and submit the form below.
Highlights
- Mow a football field in 7 minutes
- 104" width – only one in its class!
- Wide area mower with 80" transport width
- HyperDrive System
- Exclusive SmoothTrak steering
Features
104" Width
The widest width of cut in a zero-turn mower, covering a lot of ground.
HyperDrive Transmissions
Industrial grade, hydro drive system with over-sized slipper piston pumps and hot oil shuttle.
Wings Fold to 80"
80" transport width fits most trailers for easy travel between jobs.
Productivity
45% more productive than a 72" zero-turn mower.
Fuel Savings
Save on fuel due to the 104" width of cut and shorter mowing time.
Zero-Turn Maneuverability
A wide-area cut with the maneuverability of a zero-turn mower gets you in and out of areas no other wide area mower can.
Warranty
The Super 104 has the best warranty in its class in the industry. Hustler mowers are built to the highest of standards, but our unmatched warranties provide extra peace of mind. See your local Hustler® dealer for complete details.
Specs
ENGINE
Manufacturer: Vanguard
HP:
- 36HP* - Vanguard BIG BLOCK
- 37HP* - Vanguard BIG BLOCK EFI
- * Per SAE J1995
Displacement: 993 cc
Cooling: Air cooled
Air Cleaner: Heavy duty canister
Engine Warranty: 5 year (Vanguard only)
DRIVE SYSTEM
Type: Dual hydrostatic
Pumps: Danfoss DDC20
Wheel Motors: Parker TG0360
Hydraulic Lines: Stainless steel Parker seal loc technology
Hydraulic Cooling: Oil cooler with 9” fan
Reservoir Capacity: 3 gallons
Speed: 11 mph
Parking Brakes: Patented automatic
DECKS
Cutting Width: Rear discharge: 104”
Cutting Heights: 1”- 5.5”
Deck Lift: Hydraulic powered
Depth: 5.5”
Blades: 5
Blade Length:
- 1 - 23.86” x 2.50” x .20” CW
- 1 - 23.86” x 2.50” x .20” CCW
- 1 - 20.50” x 2.50” x .20” CCW
- 2 - 20.50” x 2.50” x .20” CW
Spindles: Ductile cast iron with steel shafts and sealed ball bearings
Deck Belts: 1 per deck
Drive: Electric PTO clutch
Construction: 11 ga. welded steel
Spindle Mounts: Reinforced 7 ga. doubler
Impact/Trim Areas: 1.5” x .375” steel bar protector
CONSTRUCTION
Frame: 1.5” x 3.0” x .187” steel
Front Caster Wheels: Mounted with sealed ball bearings
Front Caster Forks: Fabricated 1/2” steel
GENERAL
Seat: Grammer suspension seat, isolator platform
Fuel Capacity: 12 gallons
Cup Holder: Yes
Front Tire: 15 x 6.0 - 6
Drive Tire: 26 x 12 - 12
DIMENSIONS
Weight: 2312 lbs
Height w/ rops up: 71.5”
Height w/ rops Folded: 54”
Length: 95.5”
Width:
- 106.1” wings down
- 80.0” wings up at gauge wheels
- 72.5” wings up at deck base
Tire Width: 60.3”
PRODUCTIVITY*: 9.24 Acres Per Hour
OPTIONAL ACCESSORIES
- Mulch kit
- Steering extension kit
- Light kit
- Anti-scalp kit
- Flasher kit
- Beacon kit
