Heavy-duty lift arms, a wide variety of attachments, powerful engines... These are just some of the items that come standard when you buy Mustang. A few common features are:

- Spacious cabs with clear, panoramic views
- Powerful, clean and efficient diesel engines
- ROPS/FOPS cab tilts for easy service and maintenance access
- Ride Control system allows lift arm to float when travelling, reducing spillage
- Universal, quick-attach attachment mounting system

Key Features
- Load capacity of 1,900 lbs. and 2,050 lbs. with optional counterweight kit
- Lift height of 121.5"
- 68-hp Yanmar Interim Tier IV diesel engine
- Radial-lift arm design
- Fast ground speeds up to 12.4 mph with two-speed option
- Operator-friendly Level II-certified ROPS/FOPS
- Spacious operator compartment for more comfort and excellent visibility
- Auxiliary hydraulics of 19 gpm
- Optional high-flow auxiliary hydraulics up to 30 gpm
- Drive motors utilize SAHR (spring applied hydraulic release) brakes as standard equipment
- Safety Interlock system requires operator to be seated with restraint bar down prior to operation
- Tilt-up ROPS for easy internal service access

Steering/Hydraulic Controls
- Joystick Controls
- Hand-Foot Controls
- Dual-Hand Controls

Attachment Mounting System
- The Multi-tach mounting system offers compatible fit-up with most attachments

Features
Standard:
- Engine Auto-Shutdown System
- Engine Pre-heater - Auto
- Interim Tier IV Engine
- Auxiliary Hydraulics
- Independent Hydraulic Reservoir
- Foot and Hand Throttles
- Full Instrumentation
- Integral Access Plate (removable)
- Op. Restraint Bar w/Padded Armrests/Seat Belt
- ROPS/FOPS Level II Overhead Guard
- Sound Reduction Material
- Work Lights - Front and Rear
- Multi-Tach Attachment Mounting
- Anti-Vandalism Protection
- Brake Control (auto/manual)
- Hydraglide System
- Hydraloc System
- Hydrostatic Drive - Pilot Controlled
- Lift Arm Support Device
- Self-Leveling Lift Action

Optional:
- Joystick Controls
- Hand-Foot Controls
- Dual-Hand Controls
- High-Flow Auxiliary Hydraulics
- Air-Conditioning
- Cab Enclosure with heater
- Heater
- Horn
- Suspension Seat - Mechanical
- Back-Up Alarm
- Power-A-Tach Attachment Mounting
- Radio
- Two-Speed Drive

Dimensions
Overall Operating Height - Fully Raised (mm): 153.5" (3899)
Height to Hinge Pin - Fully Raised (mm): 121.5" (3086)
Overall Height to top of ROPS (mm): 79.4" (2017)
Ground Clearance to Chassis (mm): 7.5" (191)
Overall Length with Bucket (mm): 130" (3302)
Overall Length without Bucket (mm): 95.1" (2416)
Wheelbase (mm): 42" (1067)
Dump Reach at Full Height (mm): 22.75" (578)
Rollback at Ground Level: 23°
Dump Angle: 43°
Overall Width (mm): 63" (1600)
Overall Width - Narrow Offset Tire Option: 59.7" (1516)
Bucket Width (mm)L: 60" (1524)
Clearance Circle - Rear (mm): 57.25" (1454)
Clearance Circle - Front w/o Bucket (mm): 48" (1219)
Clearance Circle - Front w/Bucket (mm): 79.5" (2019)
Seat to Ground Height (mm): 38.5" (978)
Rollback at Full Height: 88°
Dump Height (mm): 91.75" (2330)
Departure Angle: 23°
Standard Tire Size: 12.00 x 16.5 HD
Engine: Yanmar 4TNV98 Interim Tier IV
Net Power (kW): 68 hp (50.7)
RPM for Optimal Power: 2500 rpm
Displacement (L): 202 cu.in. (3.3)
Auxiliary Hydraulics - Standard (L/min): 19 gpm (72)
High-Flow Hydraulics - Optional (L/min): 30 gpm (114)
Filtration: 12 micron
Reservoir Capacity (L): 15 gal. (56.8)
Battery: 12-volt (3.0)
Starter (kW): 12-volt (950)
Alternator: 95-amp
Rated Operating Capacity (kg): 1,900 lbs. (862)
With optional counterweight (kg): 2,050 lbs. (930)
Tipping Load (kg): 3,800 lbs. (1724)
Fuel Tank (L): 15 gal. (56.8)
Travel Speed - Maximum (km/hr): 12.4 mph (19.9)
Operating Weight - Approximate (kg): 6,900 lbs. (3130)
